LED display from China manufacturer - Shenzhen Creking Electronics Tech. Co., Ltd.

Payment Terms:	T/T,L/C,WU
Place of Origin:	, China (Mainland)

Product Detail

Model No.: CCY-P5-I1

Packing: Wooden Case or flight case

Type: Others

Silian and OPTO chips adopted: Stable and multi-function

Production Capacity: 3000sqm

Delivery Date: 15-25 days after receiving ...

Brand Name: CCY

1. High quality of indoor led display
2. ISO,CE,ETL,,CCC,UL,RoHs
3. MOQ: 1 set

1. Pixel Pitch : 5 mm

2. LED Configuration: 1R1G1B

3. LED encapsulation SMD3528

4. Module Resolution: 32X32

5. Module Size: 160X160mm

6. Cabinet Resolution 128X128

7. Cabinet Size 640X640mm

8. Optimum Viewing Distance: 5m

9. Pixel density: 40000 dots/m2

10. Brightness: >1500nit

11. Viewing Angle (H/V): 120 degrees/70 degrees

12. Frame Rate: 60Hz/s fps

13. Refresh Rate: 300Hz

14. Driving Method: 1/8 Scan, Constant Current

15. Grey Scale/Color: Display colors≥16.7m

16. Pixel Type: Real

17. Lifetime: 100,000 hours

18. Power Consumption: ≤900 watts/m2

19. Operating Temperature: -20Co—60Co

20. Working Voltage: 110-220VAC±10%

21. Weight: 15 Kg/Cabinet

22. MTBF ≥5000 hours

23. Malfunction dot rate ≤ 0.0001

24. Whole display flatness: less than 1mm juncture
